Projectiondesign F22 - Ceiling Mount

english
18
O
CEILING MOUNT
The projector can be ceiling mounted using an
approved UL tested/ listed ceiling mount fixture, with a
capacity of minimum 60 kg / 130 lbs.
For ceiling mount use M6 screws that penetrate
maximum 15 mm / 0.6” into the projector body.
For proper ventilation the minimum distance from
ceiling/ rear wall should be: 30/ 50 cm, 12/ 20 inch.
Ceiling Mount Interface
M6 Threads
384,9
111,8
94,3 15,5
95
82,5
59,5
53
123,1
163,3
300mm
500mm
