USER GUIDE SVGA LCD PROJECTOR
19
COMPUTER
Selects computer as the active source.
VIDEO *
Selects video as the active source.
S-VIDEO *
Selects S-video as the active source.
AUX **
Selects optional auxilliary input as the active
source.
POINTER
Applies a trackball-controlled pointer to the screen.
ZOOM
Press to zoom in on the image. Use the trackball
to zoom in or out. Change the zoom area by using
PAN.
PAN
Allows panning within oversized (zoomed) images
using the trackball.
LIGHT
Press to illuminate the keypad.
MENU
Invokes the menu system.
TRACK-
BALL
The trackball is mainly used to control the mouse
pointer (if the mouse cable is attached properly).
When ZOOM, MASK, PAN or MENU is invoked,
mouse control is disabled, as the trackball is used
to control these functions instead. Trackball
sensitivity, except for the mouse, is set under
OPTIONS in the menu system. Mouse sensitivity
is set at your computer as with the standard
mouse.
RIGHT
Emulates the right mouse key.
BOTTOM/
DRAG
This emulates the “click-and-hold” function of the
desktop mouse.
Use BOTTOM/DRAG key instead of RIGHT key
when connected to a Macintosh computer.
LEFT/
ENTER
Emulates the left mouse key.
Once the menu is accessed selections are
confirmed using LEFT/ENTER key.
* Video version only.
** Only when auxilliary adapter is fitted
