Installation
Figure (1)
Figure (2)
Air intake
Air exit
mini 5 cm
mini 5 mm
mini 2 cm
4
1. Cut a hole in the worktop of the dimension shown in the diagram below.
A minimum of 50 mm space should be left around the hole. The worktop
should be at least 30 mm thick and made of heat-resistant
material.
As shown in Figure (1)
2. It is essential that the induction hob is well ventilated and that the air intake
and exit are not blocked.
Make sure the hob is correctly installed as shown in Figure(2).
For safety, the gap between the hob and any cupboard above it should be at
least 760 mm.
