CASTOR ASSEMBLY
The castors must be attached to the heater before operating the
heater.
1. Carefully remove the heater, castor plates and U-bolts with
wing nuts from the packaging box.
2. Turn the heater upside down on a rug or soft surface.
3. Unscrew the wing nuts from the U-bolts.
4. Slide the U-bolt through the slot between the two oil
filled
fins.
5. Place the castor plates on both ends of the bottom of the
heater.
6. Insert both ends of U-bolts into the holes of the castor plates.
Castor plate x 2
U-bolt x
Wing nut x
Position the hooked end of the U-
bolt and insert it through the castor
late.
EN-6
