Proline PLFW115 - 2 Diagrams; Wall Hood

2 | PROLINE RANGE HOODS
Wall or Insert
A - HOOD directs heat and smoke into the hood’s internal blower system. The
blower forces heat and smoke from cooking into the chimney.
B - CHIMNEY vents air from cooking to the outside of the home.
C - CONTROL PANEL controls the hood’s various features.
D - FILTER(S) prevent grease and grime from getting into the blower(s). The
number and type of filters depends on the model.
E - LIGHTS - Two 20 watt halogen bulbs.
a
b
c
e
d
