8 13
Operating Mode Description
Operating mode LCD Display
Standby charging mode
Battery can be charged without
switching on the unit.
Utility input bypass to output, and charge the battery.
Battery is charging by PV energy only, no AC output.
Utility input bypass to output, and charging by both utility and PV.
