Installing and Wiring the Thermostat
Mounting the Thermostat into the Base Plate
The Proliphix thermostat contains jumpers to configure the HVAC power settings.
The power settings determine which HVAC power source (RH or RC) is configured to
turn on each HVAC system (cool, heat and fan). Most applications use only RH
power. The Proliphix thermostat is shipped from the factory with the “RH Only”
configuration.
Table 5 lists the possible HVAC power configurations. RC and RH are connected with
J1 inserted.
The NT100e/NT120e/NT125e can be powered from different sources presented on the
following Ethernet CAT5/5E/6 interface:
A Power over Ethernet (PoE) source is an Ethernet router, switch, or mid-span
device that complies with the 802.3af Power over Ethernet standard.
Proliphix Ethernet Power Adapters (EPA) are multi-port power injectors capable
of supplying power to either two (EPA-20) or six (EPA-60) Proliphix Network
Thermostats.
Table 6 shows how to configure the NT100e/NT120e/NT125e for two different power
sources.
Figure 5 shows the location of the jumpers on the thermostat circuit module. The
jumper in J2 supports an Up (POS1) or Down (POS2) position. The example in
Figure 5 shows the J2 jumper in the Up position. If necessary, move the jumper
downward to the POS2 position.
Table 5 HVAC Power Configuration
HVAC Power Configuration J2 J1
RH only (default) – Supplies W1, W2, Y1, Y2, G POS1 IN
RC only – Supplies W1, W2, Y1, Y2, G POS1 IN
RH and RC – RH supplies W1, W2, G and RC supplies Y1
and Y2
POS1 OUT
RH and RC – RH supplies W1 and W2 and RC supplies Y1,
Y2, G
POS2 OUT
Table 6 NT100e/NT120e/NT125e Power Source Configuration
HVAC Power Configuration J3
PoE Power Source Out
EPA-20/60 Power Source In
