PROLYTE PRODUCTS GROUP © 2001
Prolyte has made every effort to ensure the accuracy of this manual, no liability will be accepted for errors. Prolyte reserves the right to change or alter
their products or manuals without prior notice. No part of this manual may be reproduced in any form or by any means without prior written permission.
PROLYTE PRODUCTS GROUP - phone +31 (0)594 85 15 15 - fax +31 (0)594 85 15 16 - www.prolyte.com
pages 10 of 12
Performance in aluminium
Manual-MPT Tower
1. Check the building site for any obstacles that might inuence the structure or its building.
2. Make sure that the system is built on solid ground. In situations where it has to be built on
grass, sand or any unstable subsoil, under ll the screw jacks with plywood pads of 300x300x20mm
(minimum size for each screw jack), and preferably a larger one (1200 x1200x20mm) under these,
thus combining all the inner base screw jacks.
3. Follow the assembly instructions from chapter 7 up to point 20.
4. Before lifting the structure to working height apply ballast rst. Ballast/counterweights can be
composed of various elements, depending on the national or local building codes and regulations,
and the economic availability of materials. Check this with your local building inspection
authorities and/or a local structural engineer.
- Water tanks connected to the tower base
- Interconnected stage oor structure, only if this is a completely rigid such as in a
scaffolding frame. If connected by at least 4 scaffolding clamps to each lower mast
section, the weight of the stage might be taken as part of the counterweight or
ballast.
- Lighting or sound equipment
- Ground anchors
- Concrete blocks
- Canvas bags lled with sand or rubble
- Steel bars
5. Ballast has to be attached directly to each base section. The best way to do this is to place the ballast
on the long outriggers.
WARNING
Neglecting the addition of the appropriate amount of ballast and/or not applying part of the guy wires
is dangerous. Under inuence of wind this can result in failure of the complete structure.
11. Spare parts
Spare Parts:
Base-section MPT-004 SP-004-CAS Blue, swivel castor
Outriggers SP-SPIN-MPT Screw jack + dish
ACC-LP-10 Locking pin
CCS7-705 R-Spring for locking pin
Hinge-set 4xCCS6-H CCS6-H-M-135 Male (pin) hinge part
CCS6-H-FM-45 Female (fork) hinge part
ACC-LP-16 Locking pin for hinge
CCS7-705 Safety R spring
Hand winch MPT-014 SW-08-1500HOE Steel wire with hook
SP-CRANCK Crank
SP-CRANCK BOLT Wingnut for crank
ACC-LP-020 Locking pin for winch stand
CCS7-705 Safety R spring
WARNING:
NOT FOLLOWING THE GUIDELINES IN THIS MANUAL MAY CAUSE DANGER,
PROPERTY DAMAGE, INJURIES OR DEATH.
