Manual-MPT Tower
7) Measure the area where the tower needs to be and make sure there is enough room for all
components including the outriggers with the plywood padding (the free and cleared building site for
each tower, needs to be app. 3m wide, 13m deep and 14m high).(
2
)
7. ASSEMBLY INSTRUCTIONS
Assembly of a lifting-system with 4 towers (Ground support)
2
Except in the situations of hazardous objects or obstacles as mentioned above.
1. Mast section (H30V truss)
2. Base section
3. Long outrigger
4. Top section
5. Hinges
6. Hand winch/Hoist
7. Sleeve block
