1
1
2
2
A A
B B
Drawn By
Finish
Promation Engineering Inc.
16138 Flight Path Drive
Brooksville, Fl 34604
Phone: 352-544-8436
Fax: 352-544-8439
This Document is the property of ProMation Engineering,
Inc. Distribution of this document without the written
consent of the owner is Strictly forbidden.
Failure to comply will incur a liability for Damages.
Checked By
4/8/2015
P2~P3 F07 F10 Dim Data
Rev.
H
NO SCALE
Sheet Number: 1
Material
ProMation Engineering, Inc.
DJG
KHL
9/16/2020
P2_3 F07 F10 8P22 DimData.idw
Created:
Last Checked:
Part No.
Dwg. Name
Dimensional Data for P2~P3 Actuators
Engineering Change Notice
Change Date
Description
Name
04.25.13
Document transferred to Inventor format
KHL
11.12.13
Added rounded edges on Drive Coupling Data
KHL
04.15.2014
Added tolerance on drive coupling data
KHL
10.07.2014
Pushed square dimension to three
decimal places
KHL
REV
A
B
C
D
E
F
Dimensional Tolerances (Unless Otherwise Noted):
X
± 2.5mm [X.X ± .1]
X.X ± .3mm [X.XX ± .01"]
X.XX ± .13mm [X.XXX ± .005"]
ALL TOLERANCE FEATURES IN mm
G
04.08.2015
Added Isometric view of Drive Coupling and "Depth" tag for clarity
KHL
H
09.16.20
Added F10 mount
DJG
Drive Coupling Fabrication Data
22.00
-
.13
.00
+
mm
0.866
-
0.005
0.000
+
in
22.00
-
.13
.00
+
mm
0.866
-
0.005
0.000
+
in
30.00 mm
1.181 in
Depth
30.00 mm
1.181 in
324 mm
12.8 in
210 mm
8.3 in
229 mm
9.0 in
189 mm
7.5 in
123 mm
4.8 in
300 mm
11.8 in
Add 257mm
[10.1"] to allow
for cover
removal
96 mm
3.8 in
102.0 mm
4.02 in
ISO 5211 F10
(4) M10x1.25
24mm 1"
22.0 mm
0.866 in
Square
(2) 3/4" NPT
EMT Entry
88 mm
3.4 in
124 mm
4.9 in
166 mm
6.5 in
100 mm
3.9 in
8 mm
0.3 in
132 mm
5.2 in
70.0 mm
2.76 in
ISO 5211 F07
(4) M8x1.25
20mm 0.8"
To Next Page
