Advanced Test Products Europe RG5410A-E
- 11 -
PARTS LIST RG5410A
-E
Pos. Description Part No. 1 Plasic case 100134 L&R 2 Fan grill 100505 3 Axial fan EL1818 4 Condenser CD1201 5 Motor EL1822 6 Coupler CP1315 7 Bell housing CP1001 8 Compressor CP1320 9 Fuse – 5x20mm 110-200347-001 10 Input gauge GA1500 11 Output gauge GA0800 12 Gauge lens GA1000 13 ON/OFF switch EL1310 14 Start switch EL1309 15 Blue knob 100123 16 Red knob 100124 17 Black knob 100122 18 Frontpanel 110-200395-001 19 Filter 100343 20 Flare cap NB6501 21 Powercord 135-200341-001 22 High Pressure switch 100339 23 Rear panel 100318 24 Select Switch 105-200396-001 25 Compressor Bracket 100207 26 Manifold 535395ASM 27 Hose 4“ 100345 28 Fuse holder 100419 29 VAC Sensor 113726
100134 L&R 100505 EL1818 CD1201 EL1822 CP1315 CP1001 CP1320 100406 GA1500 GA0800 GA1000 EL1310 EL1309 100123 100124 100122 110-200395-001 100343 NB6501 135-200341-001 EL2802 100318 105-200396-001 100207 700009 100345 100419 113726
