5 ActivTable Quick Start Guide
Connectivity Panels
The ActivTable has two connectivity panels installed under the ActivTable, at either end.
The Main Connectivity Panel contains.
The Secondary Connectivity Panel contains.
Brakes
Three of the legs are tted with brakes to prevent the table moving when in use. See the Safety Information Guide (TP1844)
for instructions on the brakes.
USB Connector
Network
Connector
On Button Speaker
USB ConnectorDVI Connector
Audio
Connector
Microphone
Connector
Audio
Connector
USB Connector
Speaker
USB Connector
Audio
Connector
Audio
Connector
