BLADE START / STOP KNOB, POWER TAKE OFF (PTO) (Part 14)
The Blade Start / Stop Knob is located
on the Right Hand Console in front of the
Key Switch. The Blade Start / Stop Knob
operates the electronic motors on the
cutting deck. Pull the Knob upward to
engage the rotation of the blades or
push the Knob downward to disengage
the rotation of the blades.
KEY SWITCH (Part 15)
The Key Switch is located on the Right Hand console.
1. The Key Switch sends power to the Ignition Control Module when the switch is in
the position
2. The Key Switch sends power to both the Ignition Control Module and the LED Lights
when the switch is in the position
3. Turning the Key Switch to the position turns the machine’s power off and stops
the flow of the power to the Vehicle Control Modular.
To Next Page
