27
TIRE PRESSURE
Correct tire pressure ensures machine
stability and the correct alignment of
the blade with the ground. Periodically
check the pressure of the tires and
regulate according to the pressures
shown on the technical data table.
To inflate the tires, use an inflation gun
featuring pressure gauge (Fig 30).
Tire Pressures:
FRONT: 30 PSI (15 X 6.00 - 6)
REAR: 28 PSI (16 X 6.5 - 8)
7. CONTROLS AND OPERATIONS
CONTROLS AND CONTROL INSTRUMENTS
BLADE & DECK LIFT UP / DOWN LEVER (Parts 2 & 3)
Lifts or lowers the blade deck and
thereby adjusts the grass cutting height.
There are eight possible height
adjustments. Move the lever to the
required position. Cutting heights: see
technical data table.
Lower Cutting Height Settings has more potential for scalping
especially on uneven terrains.
