ProScan PLDED5515-B-UHD - Front View; Back View

CONTROL REFERENCE GUIDE
FRONT VIEW
5
BACK VIEW
1.Color Screen
2.Remote Sensor
Do not block this sensor or the
remote control will not work.
3.Standby Indicator
Indicates whether the unit is ON
or in STANDBY (OFF) mode.
Lightin red: The unit is in STANDBY.
Light in
blue:The unit is turned ON.
4.Speakers
6
1.Power Cor
2.Optical Out Jack
3.AV INJack
4.COMPONENT IN Jack
5.Line Out Jack
6.HDMI IN Jacks
7.TV ANTENNA Terminal
8.Service Port
d
1
Optical
Out
LR
Y(VIDEO)
Pb
Pr
Line Out
HDMI1HDMI2
HDMI3
HDMI4RF
Service
Port
