Diagrams
November 19998-11
8-3. Mechanical Spare Parts List, Assembly Drawings & Exploded Views
8-3-1. Mechanical Spare Parts List
Item Sparepart code dwg added
assy top roller ProSeal 44" SP 144-003 Y
assy bottom roller ProSeal 44" SP 144-004 Y
assy top pull roller ProSeal 44" SP 144-009 Y
assy nipknob ProSeal 44" SP 144-021 Y
assy top roller ProSeal 25" SP 144-026 Y
assy bottom roller ProSeal 25" SP 144-027 Y
assy bottom pull roller ProSeal 44" SP 144-046 Y
assy top pull roller ProSeal 25" SP 144-055 Y
assy bottom pull roller ProSeal 25" SP 144-070 Y
assy control PCB 230V, 50/60Hz SP 144-074 N
assy sensor TH4074 (ProSeal 44") SP 144-137 Y
sticker knob SP 144-138 N
assy sensor TH4075 (ProSeal 25") SP 144-143 Y
assy lh cover ProSeal SP 144-149 Y
assy control PCB 115V, 50/60Hz SP 144-152 N
heater ProSeal 44"-US 115V / 1850W SP 144-157 N
heater ProSeal 25"-US 115V / 1500W SP 144-158 N
heater ProSeal 44"-EU 230V / 1850W SP 144-159 N
heater ProSeal 25"-EU 230V / 1500W SP 144-160 N
assy top cover ProSeal 44 SP 144-164 Y
assy top cover ProSeal 25 SP 144-165 Y
assy belt tensioner ProSeal 44" SP 144-168 Y
sticker 'ProSeal 44' SP 144-171 N
sticker 'ProSeal 25' SP 144-172 N
assy rh frame ProSeal 44" - US SP 144-180 Y
assy lh frame ProSeal 44" - US / EU SP 144-181 Y
assy rh frame ProSeal 25" - US SP 144-182 Y
assy lh frame ProSeal 25" - US / EU SP 144-183 Y
assy rh arm (compl.) ProSeal 44" SP 144-184 Y
assy lh arm (compl.) ProSeal 44" SP 144-185 Y
assy rh arm (compl.) ProSeal 25" SP 144-186 Y
assy lh arm (compl.) ProSeal 25" SP 144-187 Y
assy top pouch guide PrSl 44" SP 144-188 Y
assy top pouch guide PrSl 25" SP 144-189 Y
assy rh arm pull roller (compl.) SP 144-190 Y
assy lh arm pull roller (compl.) SP 144-191 Y
assy rh cover (compl.) ProSeal SP 144-194 Y
assy nipknob ProSeal 25" SP 144-195 Y
assy lh interlock top cover SP 144-198 Y
assy rh frame ProSeal 44" - EU SP 144-201 Y
assy lh frame ProSeal 25" - EU SP 144-202 Y
assy rh interlock top cover SP 144-204 Y
assy rear sheet ProSeal 44" -US SP 144-206 Y
assy US Power Cable 20A SP 144-208 Y
assy rear sheet ProSeal 25" - US SP 144-210 Y
assy US Power Cable 15A SP 144-211 Y
assy feed-in table ProSeal 25' SP 144-230 Y
assy feed-in table ProSeal 44" SP 144-231 Y
assy rear sheet ProSeal 44" - EU SP 144-234 Y
assy rear sheet ProSeal 25" - EU SP 144-235 Y
assy belt tensioner ProSeal 25" - EU SP 144-237 Y
drive belt ProSeal 44 SP 956-0002 N
drive belt ProSeal 25 SP 956-0003 N
machine foot SP 957-0000 N
