1.1 System Requirements
The MVI56E-MCMXT & MN/I56E-MCM module requires the following minimum hardware
and software components:
• Rockwell Automation® ControlLogix™ processor (firmware version 16 or higher), with
compatible power supply, and one free slot in the rack for the MVI56E-MCMXT &
MN/I56E-MCM module. The module requires 800mA of available 5 VDC power
• Rockwell Automation RSLogix 5000 programming software
o Version 16 or higher required for Add-On Instruction
o Version 15 or lower must use Sample Ladder, available from
http://www.prosoft-technology.com
• Rockwell Automation RSLinx communication software version 2.51 or higher
• Pentium® II 450 MHz minimum. Pentium III 733 MHz (or better) recommended
• Supported operating systems: o Microsoft Windows Vista
o Microsoft Windows XP Professional with Service Pack 1 or 2
o Microsoft Windows 2000 Professional with Service Pack 1, 2, or 3
o Microsoft Windows Server 2003
• 128 Mbytes of RAM minimum, 256 Mbytes of RAM recommended
• 100 Mbytes of free hard disk space (or more based on application requirements)
• 256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color 1024 x 768
recommended)
• CD-ROM drive
• ProSoft Configuration Builder (PCB) (included)
• ProSoft Discovery Service (PDS) (included in PCB)
Note: The Hardware and Operating System requirements in this list are the minimum recommended to install
and run software provided by ProSoft Technology. Other third party applications may have different minimum
requirements. Refer to the documentation for any third party applications for system requirements.
Note: You can install the module in a local or remote rack. For remote rack installation, the module requires
EtherNet/IP or ControlNet communication with the processor.
