8 Serial Communication Parameters for the Modbus network:
Baud rate?
Data bits?
Parity?
Stop bits?
Required for both Master and Slave configurations.
9 Wiring type to use (RS232, 422 or 485). Configured by jumper settings.
Required for proper implementation of the module in Master and Slave configurations.
Note: If you are installing your module into a new system, and plan to use our Sample Ladder
Logic, refer to the printed Quick Start Guide in the module carton for simple installation procedures.
• For version 16 or newer of RSLogix 5000, refer to Using the RSLogix 5000 v16 Add-On
Instruction (page 33).
• For EXISTING system installations, refer to Integrating the Sample Ladder Logic into an
Existing Project (page 180).
Note: Most applications can use the Sample Ladder Logic without modifying the sample program.
1.3 Package Contents
The following components are included with your MVI56E-MCMXT & MN/I56E-MCM
module, and are all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name Part Number Part Description
1 MN/I56E-MCM
XT &
MVI56E-MCM
Module
MVI56E-MCMXT &
MN/I56E-MCM
Modbus Communication Module
1 Cable RL-CBL025 5 foot Ethernet Straight-Through Cable (Gray)
2 Cable Cable #14, RJ45 to
DB9 Male Adapter
cable
For DB9 Connection to Module’s Application
Serial Port
2 Adapter 1454-9F Two Adapters, DB9 Female to Screw Terminal.
For RS422 or RS485 Connections to Port 1 and
2 of the Module
1 inRAx
Solutions CD
Contains ProSoft Configuration Builder (PCB)
and ProSoft Discovery Service (PDS) for the
MVI56E-MCMXT & MVI56E-MCM modules.
If any of these components are missing, please contact ProSoft Technology Support for
replacement parts.
