11
Location: Located in the bathroom or in other locations where there is
temporary excess humidity or pollutants.
Purpose: To eliminate excess humidity produced by showers or other
periodic activities producing pollutants.
20/40/60-MINUTE PUSH-B
UTTON TIMER:
Activate the push button. Within 2 seconds, push
one time for 20 minutes, two times for 40 minutes
or three times for a 60-minute activation.
Results e
xpected:
1. Motor speed: high for 20, 40 or 60 minutes.
2. Indicator light goes “ON” and flashes every
5 seconds (one time to indicate a 20-minute
operation, two times for a 40-minute, and three
times for a 60-minute operation).
3. Air exchange indicator light goes “ON” (VALUE
wall control only).
NOTE: To stop activation, push one more time.
2.4 USING THE OPTIONAL CONTROL
VC0046
20 min.
40 min.
60 min.
