INSTALLER/CONFIGURATION MENU
To enter the menu: Press the Menu touch key. Press and hold for 5 seconds the Installer Confi g touch key. When the key is
released the display will show menu item #1 in the table below. Press
to advance to the next menu item or to return to a
previous menu item. Press
or to change a menu item.
CONFIGURATION MENU
Menu
Reference
Number
Program-
mable
Non-
Program-
mable
Press
Button
Displayed
(Factory
Default)
Press
or
to select from
listed options
Comments
1 1 1 MS 2 HP 1, HP 2, SS 1 Selects Multi-Stage (MS 2, No Heat Pump), Heat Pump 1
(HP 1, 1 compressor), Heat Pump 2 (HP 2, 2 compressor
or 2 speed compressor), or Single Stage.
222 (GAS) ELE GAS setting: furnace controls blower.
ELE setting: thermostat controls blower.
333 Days, (7) P 0 Programs per week. (5 = 5+1+1 day, 0 = non-programmable)
44NA
PS (4)
Morning, Day,
Evening,
Night
2
Day, Night
Program periods per day.
4 = Morning, Day, Evening, Night
2 = Day, Night
554 Cool-Off-
Heat-Auto
Cool-Off-Heat,
Off-Heat, Cool-Off
System switch confi guration in non heat pump mode.
Cool-Off-
Heat-
Em-Auto
Cool-Off-Heat-Em,
Off-Heat-Em, Cool-
Off
System switch confi guration, heat pump mode.
66NA E (On) OFF Selects Energy Management Recovery, E (with program-
ming option on)
775 Cr, Heat (FA) SL Selects Adjustable Anticipation, cycle rate, Heat
886
Cr, Cool (FA) SL Selects Adjustable Anticipation, cycle rate, Cool
997
Cr/AU, Em
(FA)
SL Selects Adjustable Anticipation, cycle rate auxiliary, (This
item is only to appear if HP 1 or HP 2 is selected above).
10 10 8 CL (OFF) On Selects Compressor Lockout.
11 11 9
dL (On) OFF Selects Continuous Display backlight & intensity.
12 12 10
dL (LO) HI Selects Backlight Intensity.
13 13 11
0 4, LO to 4, HI Selects Adjustable Ambient Temperature Display [range -4
(LO) to +4 (HI)].
14 14 12
°F °C Selects °F/°C Display (temperature units in Fahrenheit or
Celsius).
15 15 13 b (On) OFF Selects audible Beeper On/Off.
16 16 14
dS (On) OFF Selects Daylight Saving Time calculation.
17 17 15
AS, Heat
(OFF)
On Selects Automatic Schedule for comfort temperature Pro-
gramming, heat mode.
18 18 16 AS, Cool
(OFF)
On Selects Automatic Schedule for comfort temperature Pro-
gramming, cool mode.
19 19 17 CS, (OFF)
Cool Savings
1-2-3-4-5-6 Selects Cool Saving Feature & amount.
20 20 18 HL, Heat (99) 62-98 TEMPERATURE LIMIT, HEAT (max. heat set point).
21 21 19
LL, Cool (45) 46-82 TEMPERATURE LIMIT, COOL (min. cool set point).
22 22 20
OFF,
Keypad
Lockout
L (total), P (partial),
Temperature Limit
(limited temperature
range)
Selects Keypad Lockout.
000 001-999 Selects Keypad Lockout Combination (active only if keypad
Lockout is selected).
23 23 21 FS, Heat (On) OFF Fast second stage of heat (not available if SS1 is selected
above).
24 24 22 FS, Cool (On) OFF Fast second stage of cool (not available if SS1 or HP1 is
selected above).
25 25 23 Remote (OFF) On Remote temperature sensor, enable/disable.
In, Remote Outdoor Remote Remote temperature sensor (Indoor/Outdoor).
LS (On) OFF Local temp. Sensor enable/disable (only when Indoor Re-
mote is selected On).
26 26 24 dF (05) 5-50 Selects Dual Fuel setpoint (°F) with outdoor sensor avail-
able. (This item appears if HP of HP2 is selected and
outdoor sensor is installed and enabled.)
Cd (15) 0-99 Selects compressor delay in seconds. (This appears if dF is
selected higher than 5.)
To Next Page
