Telescopic Arm Control
Operating the Telescopic control lever extends and retracts the inner slew
arm through 800mm.
As the control is mounted to the inner slew arm, it will move with operation of
the telescopic control. The operator must work in the control area of the post
driver to avoid all trapping zones.
Hydraulic Rear Leg Control
Operating the Rear Leg control lever extends and retracts the leg and foot
plate which is powered down once the mast in position to stabilise the
machine during the post driving operation.
Feet must be kept clear from this crushing zone during operation of this
control.
