SRT-2 • 17
Assembly of the radio plate / Montage van de radioplaat
Montierung des Radio Platine / Assemblage de la platine radio
2,9x13mm
T63.001
T63.010
T63.014
M3x8mm
M3x8mm
T63.005
2,9x6,5mm
2,9x9,5mm
2,9x9,5mm
2,9x9,5mm
2,9x9,5mm
2,9x9,5mm
