protech YADA ST - Servo Saver Assembly; Servo Saver and Shaft Assembly

13
Assembly of the servo saver / Montage van de servo saver
Assemblage du sauve-servo / Montierung des Servo Saver
Servo Saver
O-ring
T30.063
Ball Bearing
T30.146
Servo Saver Shaft
T30.062
Servo Saver Shaft
Spring Cap
T30.063
NUT LOCK
NUT LOCK
R/H 3 x 8mm
T30.210
Steering Plate (*)
R/H 3 x 8mm
T30.210
Long Ball 6mm
T30.099
Servo Saver Arm Bushing
T30.097
Ball Bearing
T30.146
Spring
T30.063
Spring Bushing
T30.063
Servo Arm Top
T30.063
Servo Arm Left
T30.063
Ball 7mm
T30.116
R/H 3 x 8mm
T30.210
NUT LOCK
Servo Saver Pie
T30.063
Servo Arm Bottom
T30.063
Ball Bearing
T30.146
R/H 3 x 8mm
T30.210
NUT LOCK
R/H 3mm x 8mm (x2)
SERVO SAVER COMPLETE: T30.063
Ball Bearing
T30.14
Stud lock
A601
Nut lock
A600
YADA ST = 6061 steering plate T30.081
YADA PRO = 7075 CNC lighten steering plate T31.210
YADA PRO-X = 7075 CNC lighten steering plate-X T31.237
*
