1. GENERAL SAFETY PRECAUTIONS
2. INTENDED USE AND APPLICATION
Double-leaf composition
Motors
Pillar brackets S1
Gate brackets S3
Fixing pack PR1-G1
Release key
Installation manual
2.1 KIT CONTENTS
n°2
n°2
n°2
n°2
n°2
n°1
This manual contains important information concerning personal safety. An incorrect installation or an improper use may lead to severe injuries.
Read carefully and store for future use. Pay particular attention to this symbol
Switch the power OFF before any operation. Double check the electrical grounding and fit a disconnection
device as well as overcurrent protection.
The installation of automatic doors and gates must comply with the Machine Directive 2006/42/CE, in particular EN 12453, EN 12635, EN 60204-1,
EN 12978. The definitive connection to the power supply, as well as testing and starting shall be performed by qualified personnel, who will beheld to
check risks and ensure the system complies with the current regulation. This product has been designed only for its intended use. Any other use could
affect the integrity and safety of the product, therefore has to be considered prohibited.
Periodically examine the automation and check for signs of wear or damage in cables and mechanical devices.
In the event that maintenance or repair is required, avoid using the automation until the installation has been fully restored.
Keep the remote controls away from children. Do not allow children to play within the system area.
Use only original spare parts. No alteration on the system has to be carried out.
Proteco Srl will not respond in case of using additional and/or fake spares.
People with reduced physical, sensory, mental or limited experience and / or knowledge can use automation only
if they are provided with supervision or specific instructions regarding the safe use of the same.
The ELITE NEW operator is designed to automate swing gates. The use of this product for purposes other than those described above and installation
executed in a manner other than as instructed in this technical manual are prohibited. All ELITE NEW systems are irreversible, therefore no electric-lock
is needed. In case of power cut the gate operator can be easily released by manual operation.
