Proteco LEADER 3 User Manual

LEADER TA
2
170
190
(24V)
Leader 3 TI = 665 - Leader 4 TI = 765 - Leader 5 TI = 865 mm
Leader 3 TI = 965 - Leader 4 TI = 1165 - Leader 5 TI = 1365 mm
Leader 4 TA = 885
170
190
(24V)
Leader 3 Leader 4 Leader 5
230V ~ 50Hz 230V ~ 50Hz 230V ~ 50Hz
1,2 - 1,7A 1,2 - 2A 1,2 - 1,7A
280W 280W 280W
8µF 8µF 8µF
150°C 150°C 150°C
2800 N 2800 N 2800 N
44 44 44
1400 rpm 1400 rpm 1400 rpm
110° deg 110° deg 110° deg
17” 22” 27”
350 Kg 350 Kg 250 Kg
2 m 2,75 m 3,5 m
40% 40% 40%
Leader 3 24 Leader 4 24 Leader 5 24 Leader 3 115 Leader 4 115 Leader 5 115
24V dc 24V dc 24V dc 115V ~ 60Hz 115V ~ 60Hz 115V ~ 60 Hz
0,5 - 0,75A 0,5 - 0,75A 0,5 - 0,75A 2,0 - 2,3A 2,0 - 2,3A 2,0 - 2,3A
50W 50W 50W 300W 300W 300W
__ __ __ 30µF 30µF 30µF
__ __ __ 150°C 150°C 150°C
2500 N 2500 N 2500 N 3000 N 3000 N 3000 N
44 44 44 44 44 44
1600 rpm 1600 rpm 1600 rpm 1700 rpm 1700 rpm 1700 rpm
110° deg 110° deg 110° deg 110° deg 110° deg 110° deg
15” 20” 25” 14” 18” 22”
275 Kg 250 Kg 150 Kg 300 Kg 250 kg 200 kg
2,0 m 2,5 m 3,0 m 2,0 m 2,75 m 3,50 m
80% 80% 80% 40% 40% 40%
LEADER TI
LEADER TA
Leader 4 TA Leader 4 TA 24 Leader 4 TA 115
230V ~ 50Hz
1,2 - 1,7A
280W
8µF
150°C
2800 N
44
1400 rpm
110° deg
22”
300 Kg
2,75 m
40%
24V dc
0,5 - 0,75A
50W
__
__
2500 N
44
1600 rpm
110° deg
20”
200 Kg
2,5 m
80%
115V ~ 60Hz
2,0 - 2,3A
300W
30µF
150°C
3000 N
44
1700 rpm
110° deg
18”
200 Kg
2,75 m
40%
LEADER TI
1
2
3 4
5
1
2
3 4
5
Motor power supply
Max draw.
Power
Capacitor
Thermal protection
Adjustable thrust
Protection rating
Revolutions
Opening angle
Opening time (90°)
Leaf weight
Leaf length
Duty cycle
2.2 KIT CONTENT
Motor power supply
Max draw.
Power
Capacitor
Thermal protection
Adjustable thrust
Protection rating
Revolutions
Opening angle
Opening time (90°)
Leaf weight
Leaf length
Duty cycle
1 LEADER Swing operator
2 SPIP0770 Rear RH bracket T1
SPIP0870 Rear LH bracket T1
3 MGR1410Z Fixing pack
MPE1226
4 SPIA0270 Front bracket S3
5 Release key
1 LEADER Swing operator
2 SPIP0770 Rear RH bracket T1
SPIP0870 Rear LH bracket T1
3 MGR1410Z Fixing pack
MPE1226
MRO12Z
MDAM12AB
4 SPIA0370 Front bracket S4
5 Release key
2.3 DIMENSIONS
