Protect FOQUS - DIP Switch Settings and Configuration; DIP Switch Functions; Configuration Examples for Voltage Variants

FOQUS
TM
230V & 115/127V
DIP Settings Fog Time Fog Volume
DIP 2 DIP 3 DIP 4
OFF OFF OFF - Do not use
ON OFF OFF - 8 m
2
OFF ON OFF - 16 m
2
ON ON OFF - 25 m
2
OFF OFF ON - 10 sec. of fog + 3 pulse shots (in all about 90 sec. fog)
ON OFF ON - 10 sec. of fog + 6 pulse shots (in all about 180 sec. fog)
OFF ON ON -
6 sec. of fog (full speed) + 294 sec. of fog
(reduced speed). In all 300 sec. fog
ON ON ON -
5 sec. of fog (at normal speed)
+ 5 min. of continuous fog (at very slow speed)
DIP switch settings
DIP
Function
1
Heat disable
On = The heating element disconnects
if disable is activated
2
Fog time
3 Fog time
4 Fog time
5 Arm*
6 Primary*
7 Secondary*
8
Fire-alarm delay**
9
Reserved.
Leave in OFF position
10
Error indicator
On = Beeper connected
* ON = normal open
OFF = normal closed
** ON = delay is active
