WIRELESS EXHAUST AIR CONTROLLER AS-7000
CENTRAL UNIT
(1) Central unit (receiver)
(2) Power LED
(3) Window transmitter LED
(4) Stove transmitter LED
(5) Roller shutter transmitter LED
(6) Test button
(7) Reset button (paper clip)
(8) Microfuse 8A fast-acting
(S) Plug guard
1
2
3
7
4
6
5
S
8
THE PLUG GUARD
must be fitted!
