WINDOW TRANSMITTER
EN
(9) Window transmitter
(10) Status LED on window transmitter
(11) Learn button on window transmitter
(12) Select jumper ‘AND/OR’
(13) Battery CR2477
(14) Magnet
(U) Packer parts
12
Open the casing by lifting the
side with a screwdriver
+
Battery
CR 2477
U14
Tophousing
Magnet
Screws
Bottomhousing
Washers
(optional)
10
9
11
13
Magnet
Washers
Window casement
Window frame
Transmitter
