Protector PRO-LUX 7000 - Thermo Transmitter Components; Thermo Transmitter Unit; Thermo Transmitter Indicators and Controls; Connection and Power

EN
24
(15) Thermo transmitter
(16) Status LED thermo transmitter
(17) Learn button thermo transmitter
(18) Connection thermo transmitter
(19) Battery compartment 2 x AA
T = Thermal sensor
B = Mounting bracket
THERMO TRANSMITTER
(a) Holes for screws
(b) Hole for thermal sensor
(Figure 3)
T
a
b
B
Flue pipe
Distance to
the fireplace
minimum
50 cm!
15
19
17
18
16
