Protek 3003B - 2. SPECIFICATION

2. SPECIFICATION
MODEL 3003 3005 3006 3015 3032 3033
Output DC voltage
Output DC current
0-30V
0-3A
0-30V
0-5A
0-60V
0-1.5A
0-30V
0-1.5A
DUAL
0-30V
0 - 3A
DUAL
0 - 30V
0 - 1.5A
DUAL
5V, 5A FIXED
Load Regulation (Load Effect) ≤ 0.02% + 2mV
≤ 0.05% + 5mA
Line Regulation (Source Effect) ≤ 0.02% + 2mV
≤ 0.05% + 0.25mA
Ripple & Noise V, A ≤ 0.2mV(rms), 4mV(p-p)
≤ 2mA(rms), 10mA(p-p)
Tracking Error ± (0.5% rdg + 1dgt)
Fixed 5V, 5A
Output V, A
5V ± 2.5%
5A ± 2.5%
Ripple & Noise 2mV (rms)
Line & Load Regulation 0.1% ± 5mV
Digital Display
V, A, Accuracy
3 dgts
3 dgts
± (0.5% rdg+ldgt)
Temperature V
Coefficient A
≤ 0.05%+2mV/°C
≤ 0.1% + 2mA/°C
Temperature Range 0 to 35 °C for rated output.
derate current 1% per degree C between 35 - 40°C.
Dimension (mm)
W x H x D
124 x 160 x 326 234 x 160 x 326
Weight (kg) 5 kg 7.5 kg
