STEP 5.
CONNECT EXTENSION CABLE WIRE ( 08 ) &
GRIP PULSE WIRE ( 10 ) TO THE COMPUTER
( 07 )
THEN FIX IT ONTO HANDLEBAR POST BY
USING SCREWS ( 39 ).
( PLEASE REFER TO FIG. G )
STEP 6.
ATTACH WATER BOTTLE RACK ( 53 ) TO
HANDLEBAR POST ( 02 ) WITH M5
SCREWS ( 55 ) THEN ATTACH WATER
BOTTLE ( 54 ) INTO WATER BOTTLE RACK
( 53 )
( PLEASE REFER TO FIG. H )
" THE BATTERIES MUST BE REMOVED FROM THE APPLIANCE BEFORE IT IS
SCRAPPED AND THAT THEY ARE DISPOSED OF SAFELY ".
NOTE : THE MACHINE IS REQUESTED TO USE AC ADAPTER, WHICH SHOULD
BE WITH OUTPUT 6V/1000 MA, PLEASE ALSO REFER TO MONITOR
INSTRUCTION FOR THE PROPER SPECIFICATION INFORMATION.
NOW THE ASSEMBLY OF THE ERGOMETER MAGNETIC PROGRAMMABLE ELLIPTICAL IS
DONE.
