Proteus IMT-7500 - Operating Ranges; Things You Should Know before Exercising; Loading Profiles; Backlight Function

L. LOADING PROFILES : THERE ARE 10 COLUMNS OF LOADING BARS, AND 8 BARS IN EACH
COLUMN. EACH COLUMN REPRESENTS 3 MINUTES WORKOUT ( WITHOUT THE CHANGE
OF TIME VALUE ), AND EACH BAR REPRESENTS 2 LEVELS OF LOADING.
M. BACKLIGHT FUNCTION
PRESS THE START BUTTON AND THE BACKLIGHT WILL TURN ON.
PRESS THE STOP BUTTON AND THE BACKLIGHT WILL TURN OFF.
OPERATING RANGES
AUTO POWER ON / OFF : DURING FOUR MINUTES WITHOUT ANY SIGNAL INPUT TO
COMPUTER ,COMPUTER WILL GO INTO SLEEP MODE. WHEN PRESS START / PAUSE KEY OR
START WORKOUT AGAIN, THE COMPUTER WILL AUTOMATICALLY POWER ON.
THINGS YOU SHOULD KNOW BEFORE EXERCISING
A. THE VALUES CALCULATED OR MEASURED BY THE COMPUTER ARE FOR EXERCISE
PURPOSE ONLY, NOT FOR MEDICAL PURPOSE.
B. BEFORE OPERATE THIS COMPUTER, BE MAKE SURE TO PLUG THE CONNECTOR OF
ADAPTOR. THE ADAPTOR SPECIFICATION REQUEST 6VDC / 1A OUTPUT.
C. THE VARIABLES MAY NEED TO CHANGE IN THE PROGRAMS :
PLEASE NOTE THAT ONLY 1 VALUE OF TIME OR DISTANCE CAN BE ADJUSTED. BOTH
ADJUSTMENTS DO NOT EXIST AT THE SAME TIME. FOR EXAMPLE, THE VALUE OF DISTANCE
IS 0.0 WHILE THE VALUE OF TIME IS ADJUSTED TO BE ANY NUMBER EXCEPT 00:00 .
PROGRAM 1~15 15~1 1 1
LEVEL 1~16 16~1 N/A 1
GENDER MALE,FEMALE N/A MALE N/A
TIME( MANUAL ) 0:00~99:59 99:00~5:00( 1:00 ) 0:00 1:00
HEIGHTCM/INCH 110.0~199.5/3'8~6'5 199.5~110.0/6'5~3'8 175.0/5'9" 0.5/1
WEIGHTKG/LB 10.0~199.8/23~440 199.8~10.0/440~23 70.0/155 0.2/0.5
DISTANCE 0.0~999.0 999.0~1.0 0.0 1.0
WATT 30 ~ 300 300 ~ 30 100 10
TARGET H.R. 60 ~ 220 220 ~ 60 90 1
AGE 10 ~ 99 99 ~ 10 30 1
VALUES
RANGE
( COUNT UP )
COUNTDOWN
PRESET
INCREMENT
( DECREMENT )
PROGRAMS VARIABLES
P1 ~ P7 TIME, DISTANCE, AGE
P8 GENDER, HEIGHT, WEIGHT, AGE
P9 TIME, DISTANCE, TARGET H.R.
P10 ~ P12 TIME, DISTANCE, AGE
P13 ~ P14 TIME, DISTANCE, AGE, 10 COLUMNS
P15 TIME, DISTANCE, WATT, AGE
