MAGNETIC CYCLE ASSEMBLY INSTRUCTION
Step 8. a. Attach half moon bracket ( 38 ), handlebar ( 06 ) to handlebar post ( 05 ) and fix with
screw ( 37 ), T-knob ( 25 ) & washer ( 31 ). Do not overtighten the screw & T-knob
before the handlebar located in desired position. ( Please refers to FIG. C )
( Note To adjust angle of handlebar, by unscrewing T-knob then tighten it firmly. )
b. Insert the grip pulse wire ( 35 ) into the handlebar post and let it through the top of
monitor mounting plate.
c. Connecting wire A ( 11 ) & grip pulse wire ( 35 ) with monitor ( 08 ).
( Please refers to FIG. D )
d. Slide the monitor into mounting plate carefully.
**** Now your PEC-1900 series has been well assembled. ****
" THE BATTERIES MUST BE REMOVED FROM THE APPLIANCE BEFORE IT IS
SCRAPPED AND THAT THEY ARE DISPOSED OF SAFELY ".
- 4 -
