STEP 5. CONNECT WIRE (A)( 10 ) AND WIRE (B)( 11 ), CONNECT MONITOR CABLE ( A ) &
MONITOR CABLE (B)( 08 & 09 ), THEN ATTACH HANDLEBAR POST ( 4 ) TO MAIN
FRAME ( 01 ), FIX WITH WASHERS ( 31 ) AND BOLTS ( 28 ).
STEP 6. ASSEMBLE FOAM GRIP ( 16 ) & END CAP ( 15 ) ONTO ONE SIDE OF HANDLEBAR
( 05 ), THEN ASSEMBLE HANDLE BAR ( 05 ) ONTO HANDLE BAR POST ( 04 ), FIX
WITH WASHER ( 32 ) AND T-KNOB ( NO.25 ), ASSEMBLE FOAM GRIP ( 16 ) AND
END CAP ( 16 ) ONTO ANOTHER SIDE OF HANDLEBAR ( 05 ).ADJUST THE ANGLE
OF THE HANDLEBAR BY THE KNOB ( 25 ). TIGHTENED THE KNOB FIRMLY AFTER
ADJUSTMENT.
NOTE: USE SOME SOAP WATER AS LUBRICANT WHILE FITTING FOAM GRIPS.
STEP 7. REFER TO FIG.1 & 2, ATTACH HAND PULSE UPPER / BOTTOM COVER ( 35 / 36 )
TO HANDLEBAR ( 05 ), FIX WITH SCREWS ( 29 ).
LEAD HAND PULSE SENSOR WIRE FROM HOLE OF HANDLEBAR POST, PULL IT
OUT FROM MONITOR MOUNTING PLATE.
CONNECT MONITOR CABLE (A)( 08 ), WIRE (A)( 10 ) AND HAND PULSE SENSOR
WIRE ( 35 ) TO MONITOR ( 08 ), THEN ATTACH MONITOR ONTO MOUNTING PLATE
OF HANDLEBAR POST ( 04 ).
NOW YOUR PEC-3050 / 3250 PROGRAMMABLE MAGNETIC CYCLE HAS BEEN WELL
ASSEMBLED.
-3-
