Protool PDC 12-4 TEC Li User Manual

11
Original operating manual
1 Technical data
* Speed specifications with fully charged
battery pack.
** The maximum speed is reduced in the
lower torque stages.
2 Symbols
Cordless impact driver PDC12-4 TEC Li PDC18-4 TEC Li
Motor voltage 10,8 V 18 V
Idling speed* 1st gear 0 - 400 rpm
2nd gear 0 - 850 rpm
3rd gear 0 - 1850 rpm
4th gear 0 - 3800 rpm
Torque for easy/tough fastening applications 28/50 Nm 40/60 Nm
Adjustable torque** 1st gear 0,75 - 12 Nm
2nd gear 0,6 - 7,5 Nm
3rd gear 0,55 - 5 Nm
4th gear 0,5 - 2,7 Nm
Chuck clamping range 1,5 - 13 mm
Drill diameter max. Wood 50 mm 50 mm
Metal 12 mm 12 mm
Stone 10 mm 10 mm
Fastening in pine max.  8 mm 10 mm
Tool holder in drill spindle 1/4 ’’ 1/4 ’’
Weight without battery pack with Centrotec 1,6 kg 1,9 kg
Charger BCL 3
Mains voltage (input) 220 - 240 V ~
Mains frequency 50/60 Hz
Charging voltage (output) 10.8 - 18 V=
Rapid charging max. 3 A
Conservation charging, intermittent (NiCd, NiMH) approx. 0.06 A
Charging times for BP, BPS and BPC battery packs
Li-ion 1.5 Ah, 80 %/100 % approx. 25/35 min.
Li-ion 3.0 Ah, 80 %/100 % approx. 55/70 min.
Permitted operating temperature range -5 °C to + 45 °C
Temperature monitoring via NTC resistor
Battery pack BP 12 LiIon BP 18 LiIon
Voltage 10,8 V 18 V
Capacity 3,0 Ah 3,0 Ah
Weight 0,450 kg 0,715 kg
Warning of general danger
Risk of electric shock
Read the Operating Instructions/
Notes!
Wear ear protection.
