8.4 Tool holder in the drill spindle
[9]
Bits can be inserted directly into the hexa-
gon socket holder of the drill spindle.
8.5 Depth stop [10]
The depth stop (partly as an accessory) al-
lows the user to insert screws to a pre-
defined depth. You can set the dimension
by which the screw head protrudes above
or is recessed below the surface of the
workpiece.
Depth setting
Turn the housing [10-1] to
set the desired fastening
depth. Each detent position
changes the fastening
depth by 0.1 mm.
Sleeve A/B must be removed before a
screw can be unscrewed.
9 Working with the machine
9.1 On/Off switch [1-4]
Press = ON, release = OFF
L The speed of the machine depends on
how far the on/off switch is pressed in.
9.2 Bit depot [1-3]
Magnetic, for storing bits and bit holders.
9.3 Belt clip [1-10]
The user can attach the machine to work
clothing for short periods using the belt
clip (right/left).
9.4 Attaching the additional han-
dle[5]
Always use the additional handle.
X Position the additional handle [5-2] on
the extension of the gearbox housing
and engage the recesses on the addi-
tional handle in the lugs on the housing.
X Turn the handle until secured in posi-
tion.
L Turn the handle to adjust the position in
30° increments.
L The drilling depth can be adjusted using
the depth stop [5-1].
9.5 Acoustic warning signals
Acoustic warning signals sound and the
machine switches off in the following oper-
ating states:
10 Service and maintenance
Note the following information:
– Keep the ventilation slits on the machine
free and clean to ensure adequate cool-
ing.
– Keep the contacts on the machine, char-
ger and battery pack clean.
Information on battery packs
– Store in a cool, dry place at a tempera-
ture between 5 °C and 25 °C.
– Protect battery packs from moisture,
water and heat.
– Do not leave flat battery packs in a char-
ger disconnected from the mains power
supply for longer than one month. Dan-
ger of deep discharge!
– If you intend to store li-ion battery packs
for longer periods without use, you
should charge them to 40 % capacity
(approx. 15 min charging time).
– To avoid short circuits the battery pack
should be stored in the packaging sup-
plied.
– Significantly shorter operating times af-
ter each charge indicate that the battery
pack is worn and should be replaced with
a new one.
10.1 After-sales service and repair
Always contact the manufactur-
er or an authorised service
workshop. Find the address of
your nearest workshop at:
www.protool-online.com/ser-
vice
– Preset torque reached.
– "Block protect" - starting torque too
high.
– Machine overloaded
WARNING
Risk of injury, electric shock
X Always disconnect the battery pack from
the machine before any maintenance or
care work!
X All maintenance and repair work which
requires the motor housing to be
opened, must only be carried out by an
authorised service workshop.
