Technical data – QuaDrive
Cordless drill – Original instruction DRC 12-4 TEC DRC 18-4 TEC
Motor voltage 10.8 V 18 V
Idling speed* 1
st
gear 0 – 400/min 0 – 400/min
2
nd
gear 0 – 850/min 0 – 850/min
3
rd
gear 0 – 1850/min 0 – 1850/min
4
th
gear 0 – 3800/min 0 – 3800/min
Torque – screwing into soft/hard material 25/45 Nm 40/60 Nm
Adjustable torque** 1
st
gear 0.75 – 12 Nm 0.75 – 12 Nm
2
nd
gear 0.6 – 7.5 Nm 0.6 – 7.5 Nm
3
rd
gear 0.55 – 5 Nm 0.55 – 5 Nm
4
th
gear 0.5 – 2.7 Nm 0.5 – 2.7 Nm
Chuck clamping range 1.5 – 13 mm 1.5 – 13 mm
Max. drill diameter in wood 50 mm 50 mm
in metal 12 mm 12 mm
Screws in spruce max. diameter 8 mm 10 mm
Tool holder in drill spindle ¼″ ¼″
Weight without battery, with CENTROTEC 1.6 kg 1.9 kg
Accessories
Charger BC 3
Mains voltage (input) 230 – 240 V ~
Mains frequency 50 / 60 Hz
Charging voltage (output) 7.2 – 18 V =
Rapid charging max. 3 A
Conservation charging current, pulsating approx. 0.06 A
Charging times for:
LiIon 3.0 Ah 80% approx. 50 min. 100% approx. 65 min.
Permitted charging temperature range −5 °C to +45 °C
Temperature monitoring via NTC resistor
DRC 12-4 TEC battery packs BP 12 LiIon
Voltage 10.8 V
Capacity 3.0 Ah
Weight 0.450 kg
DRC 18-4 TEC battery packs BP 18 LiIon
Voltage 18 V
Capacity 3.0 Ah
Weight 0.715 kg
* Speed specifi cations with fully charged battery pack.
** The maximum speed is reduced in the lower torque stages.
The specifi ed illustrations are at the beginning of this operating manual.
1 Symbols
