Proxim ORiNOCO AP-800-US User Manual

Device Configuration
ORiNOCO
®
802.11n Access Points - Software Management Guide 66
5.6.3 802.1d to 802.1p
Navigate to CONFIGURATION > QoS > 802.1d to 802.1p. The 802.1d to 802.1p Mapping Table screen appears.
Figure 5-27 802.1d to 802.1p Mapping Table
Tabulated below are the ‘QoS 802.1d and 802.1p (for layer 2 policies) parameters and the method to configure the
configurable parameters:
Click OK and COMMIT, to save the configured parameters.
5.6.4 QoS Profile
Navigate to CONFIGURATION > QoS > QoS Profile. The QoS Profile screen appears.
Figure 5-28 QoS Profile
Parameter Description
802.1d Priority Represents the 802.1d priority. It is a read-only parameter and cannot be configured.
802.1p Priority Specifies the 802.1p priority mapped to the corresponding 802.1d priority. To configure,
enter the 802.1p Priority, for the corresponding 802.1d priority, in the range of 0 to 7.
