PRx Performance Murphy Rack Fold Up - Page 2

2 (701) 566-0452
1C
10
5
6
8
17
1B
9
8
7
3E
11
16
4D
4B
18
12
2A
14
2B
16
2C
1A
3A
3B
3E
3D
15
4A
4C
13
3C
Wall Bracket – Middle
Extended PUB – Right Support
Upright – Top
No.
1A
Qty.
2
Description
Wall Bracket – Left Ear
1B 2
1C 2Wall Bracket – Right Ear
2A 2
2B 4Upright – Plate
2C 2Upright – Bottom
3A 4Linkage Arm
3B 4Linkage Arm Shock
3C 8M6 x 16 Allen Bolt
3D 8M6 Nylock Nut
3E 4M8 Nylock Nut
4A 1
Extended PUB – Left Support
4B 2
Extended PUB – Bars
4C 1
Extended PUB – Arms
4D 2
M8 x 65 Lag Screw5 8
8M8 Flat Washer
8Plastic Spacer
6M16 x 35 Hex Head Bolt
M16 Nylock Nut
M16 x 80 Hex Head Bolt
No. Qty.
22
Description
M16 Flat Washer
12
2M16 x 85 Hex Head Bolt
4
6
2J-cups
7
2Footplugs
8
2Locking Pins
9
10
11
12
13
14
15
16
40M6 x 8 Tap Screws
17
2M8 x 30 Hex Head Bolt
18
2M8 x 25 Allen Bolt
90” Fold-Up Murphy Rack with Extended Pull-Up Bar (PUB)
All Parts & Tools Needed
Required Tools
Cordless drill
3/16” drill bit
Stud nder
Level
Tape measure
Pencil
Plumb line
Ratchet
24mm Socket
24mm Open-ended wrench
13mm Socket
12mm Open-ended wrench (2)
5mm Allen wrench (or 3/16”)
4mm Allen wrench (or 5/32”)
WARNING: SERIOUS INJURY OR DEATH
COULD OCCUR IF PRECAUTIONS ARE
NOT OBSERVED. PLEASE SEE PAGE 13
Rack Specications
(WxHxD)
Folded Up:
52” x 108” x 22.5”
Folded Down:
52” x 90” x 39.5”
Weight Capacity:
1000 lbs
