PS Engineering
PMA4000 Series Audio Selector Panel and Intercom System
Installation Manual
200-041-0002 Page 1-2 Rev 5, March 2007
APPROVAL BASIS – FAA- TSO C50c
The PMA4000 p/n 11942, Audio Selector Panels are FAA approved under TSO C50c (Audio Amplifiers).
All systems comply with relevant portions of EUROCAE ED-14C/DO-160D (Environmental Condi-
tions and Test Procedures for Airborne Equipment), ED12B/DO-178B (Software Considerations for
Airborne Equipment) and ED- 18/DO-214 (Audio Systems Characteristics and Minimum Operational
Performance Standards for Aircraft Audio Systems).
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
The part number 11941 unit is NOT FAA Approved.
1.4 SPECIFICATIONS
ENVIRONMENTAL Qualifications: B1CABSRXXXXXXABBBBTMXXE2XXX
Temperature Range:
Operating:
Storage
-20ºC to +55ºC
-40ºC to +85ºC
Altitude: Up to 25,000 feet in an unpressurized area of the cock-
pit.
Audio Selector/Intercom: C50c, Class A
APPLICABLE DOCUMENTS: RTCA/DO-214, RTCA/DO-160D
DIMENSIONS: Height: 1.35 in. (3.4 cm) Width: 2.40 in. (6.1 cm)
Depth: 6.50 in. (16.5 cm) behind panel
WEIGHT (With Connectors): 12.4 oz. (0.35 kg)
Voltage: 11 to 33 VDC (28 Volt w/dropping resistor)
Maximum Current: 0.25 Amp (Externally protected by a 3 Amp circuit
breaker.)
Typical operating current:
Speaker off:
Speaker on, 28V, full radio volume
100 mA
250 mA
Audio Selector Specifications
Audio selector panel input impedance:
510
Input Isolation: -60 dB (min.)
Speaker Muting: -60 dB (min.)
Speaker Output (into 4 ) with no clipping
14 VDC:
28 VDC:
2 Watts (min.)
8 Watts (min.)
Receiver Inputs: 4 (Com 1, Com 2, Nav 1, Nav 2)
Unswitched Inputs: 4 (examples: ADF, DME. GPS WPT, Marker, Autopi-
lot Disconnect, Altimeter DH)
Transmitter Selections: 2 (Com 1, Com 2)
Speaker Impedance:
4
Headphone Impedance:
150 – 1000
Headphone Output:
30 mW each headset, with < 10% THD into 150
Microphone Impedance:
150 - 600
Intercom Specifications
Intercom Positions: 4 places (with individual IntelliVox® circuits)
Music Input: 1 (Monaural)
Music Muting: >-30 dB "Soft Mute"
Distortion:
<1% THD @ 30 mW into 150
Mic Freq. Response,±3 dB: 300 Hz - 6000 Hz
Music Freq. Response,± 3 dB: 100 Hz - 18kHz
1.5 EQUIPMENT SUPPLIED
A. 1 ea. of the following units:
