Step 2. Remove the right and left panels of the blower box (D) by removing the screws that
hold them in place (E) (6X if the blower box wasn’t already installed on the furnace, 18X
if the blower box was already installed on the furnace). Keep the screws.
Note: The duct support assembly location may differ depending on the chosen
configuration when installing the blower box.
Step 3. Remove the deflector (G) inside the furnace by removing the screws (F) (4X) located in
the blower box (two on each side).
support
assembly
To Next Page
