PT M503 - Specifications

SPECIFICATIONS
Specifications are subject to change without notice
1.2 mm HVLP Spray Gun:
Air Pressure: ................................. 25 - 50 P.S.I.
Spray pattern: ......................................2-6.5 in.
Spray Head & Needle: ..........................1.2 MM
Cup capacity: ..........................................200cc
Avg. Air Consumption (CFM): .....................8-9
Fluid Inlet (NPS): ....................................3/8 in.
Air Inlet (NPS): .........................................1/4 in.
Hose Size (ID): ......................................... 3/8 in.
Controls:
• Spraypattern,fluidflowandinletairpressure
• Allpurposegunssprayprimers,basecoats,sealersandclearcoats
• Fullyadjustablespraypattern
• Lockingpressureregulatorwithpressuregauge
• 600ccPaintCupand200ccpaintcup
• Includes,multi-wrench,cleaningbrush,socketandfluidfilter
TABLE OF CONTENTS
Specifications .....................................................................................................................................2
Important Safety Information ............................................................................................................3
Maintenance & Inspection .................................................................................................................4
Operating Instructions .......................................................................................................................4
1.2 mm HVLP SPRAY GUN Parts List ...............................................................................................5
1.5 mm HVLP SPRAY GUN Parts List ...............................................................................................6
Troubleshooting Chart .......................................................................................................................7
Replacement Parts List......................................................................................................................8
Warranty Information .........................................................................................................................8
1.5 mm HVLP Spray Gun:
Air Pressure: ................................. 20 - 65 P.S.I.
Spray pattern: .........................................3-7 in.
Spray Head & Needle: ..........................1.5 MM
Cup capacity: ..........................................600cc
Avg. Air Consumption (CFM): .....................7-9
Fluid Inlet (NPS): ....................................3/8 in.
Air Inlet (NPS): .........................................1/4 in.
Hose Size (ID): ......................................... 3/8 in.
