PTZ Optics Webcam v2 - Product Specifications

Page 3 of 6
Rev 1.0 9/20
Product Specifications
Model
PT-WEBCAM-80-v2
Type
PTZOptics Webcam
Camera
Video System
1080p-30/25, 720p-30/25, 960x540p-30/25, 640x360p-30/25
50Hz: 1fps ~ 25fps, 60Hz: 1fps ~ 30fps
Sensor
1/2.7", CMOS, Effective Pixel: 2.07M
Scanning Mode
Progressive
Lens
F=3.5mm
Minimal Illumination
0.5 Lux @ (F2.0, AGC ON)
Camera Bracket
Bracket with damper
Shutter
1/30s ~ 1/10000s
White Balance
Auto, Indoor, Outdoor, One Push, Manual
Backlight Compensation
Support
Digital Noise Reduction
2D & 3D Digital Noise Reduction
Video S/N
≥55dB
Horizontal Angle of View
80°
H & V flip
Support
Input/Output Interface
HD Output
1 x USB: Version 2.0
Audio Output
1 x Internal Microphone Array
Generic Specification
Input Voltage
5V (USB Power Supply)
Operating Temperature
-10°C ~ 40°C (14°F ~ 104°F)
Storage Temperature
-40°C ~ 60°C (-40°F ~ 140°F)
Current Consumption
200mA
Power Consumption
1W (Max)
MTBF
>30000h
Size
118mm x 37.2mm x 30.8mm (not including bracket)
Net Weight
0.35 lbs [0.16 kg]
