T-937S lead-free reflow oven user manual
6
/
9
4) Press “Room Temp” into interface below:
Need to calibrate the room temperature before using for the first time.
Press“OK ” button---
a. If the room temperature is higher than 40℃, the password box will pop up,users need to enter the
correct password, click the “ok”button --- click the "Display" button, -click .Then turn on the
machine again. Enter room temp interface ,It will show the correct room temperature ,just quit the interface
to other functions.
Soldering duration time
Preset temp of the curve
Real-time temp of the solder
Heating lamp
Cooling fan
Press “ Reset” after
soldering finishes
