LED SMT Reflow Oven T-980 User Manual
Https://www.te168.com
2
/
11
Features:
1. T-980 selects the IR and hot air heating technology controlling, equipped with
special design wind wheel, speed stability and uniform temperature, suit for
uninterrupted soldering the LED and BGA components.
2. Equipped with the crawler-type and 8 temperature-zone heating systems, each
temperature zone uses independent PID controlling and up-down heating type, can
make the inside temperature more accurate and well-proportioned, just take about
20 minutes can let it heat up to the working temperature from the room temperature.
3. Intelligent temperature wave heating type, oversized capacity wave selection,
have eight temperature waves can satisfy various welding technological
requirements.
4. Programmable technology, preset the temperature wave memory storage function,
can complete the whole welding process automatically.
5. Adopts the thermocouple temperature measurement , adds the compensation
circuit, makes the temperature measurement more accurate, the wave more perfect.
6. Uses PID intelligent temperature control technology; makes the temperature
control more accurately. Adopts the imported large current solid-state relay
non-contact output can effectively avoid the IC or circuit board damage due to the
rapid or uninterrupted warming up, make the whole welding process more scientific
safety.
7. The transmission system adopts stepping motor and stepping motor driver, which
runs stably with adjustable speed range of 0-600mm / min,2mm/s-12mm/s.
8. Adopts independent wheel structure and special stainless steel strut, durable
wear-resisting runs smoothly, speed precision can reach ±10mm/min.
9. Independent cooling zone, to ensure the PCB in low temperature when out of the
oven.
10.Adopts advanced touch screen control technology, which integrates machine
operation,function display and monitoring, making the working state display more
intuitive, heating process more clear, and operation more convenient.Facilitate
product upgrading.
11.Ergonomic design, practical and easily operated.
Good build quality.Technology - based concept is constant.
12. Preheating modes:
(1) Sequential preheating: switch on heating zones in turn.
(Advantages: small instantaneous power, low machine load, available for 220V .
Disadvantages: long preheating time);
(2) Synchronous preheating: switch on heating zones at the same time
(Advantages: short preheating time.
Disadvantages: power is too large, recommended to use 380V industrial
electricity).
