13. Digital Clock : It indicates time in HR : M (AM/PM)
14. Speedometer: Vehicle speed will be displayed in
digital form in Km / Hr.
15. Odometer : The Odometer shows the total distance
that the vehicle has covered. Odometer can't be
reset to ‘Zero’.
16. Trip Meter : Trip 1 & Trip 2 shows the distance
traveled since it was last reset to zero.
17. Set Button : Set button used for setting Clock &
Service reminder.
18. Reserve Indicator : It blinks continuously when
petrol level in tank reaches reserve level ( 1 bar or
less)
10.
RPM crosses 9500 RPM.
11. Service Reminder ( ): ‘Spanner’ symbol glows
when ODO meter reading reaches set Kms. for
service. This Icon will flash at -
st nd
1 : 450 km 2 : 4950 km,
rd th
3 : 9950 km, 4 : 14950 km
and subsequently at each 5000 kms. Icon will
continue to glow till it is reset. This icon is to be
reset after service is carried out.
12. Side Stand Indicator : When side stand is ‘ON’ .
Side Stand Indicator will light.
Engine Over Rev Indicator : It glows when engine
Speedometer Details
10
S
M
Speedometer Details
11
16
17
18
12
13
15
14
10
To Next Page
