Pulsar AS 150 User Manual

Control Switches
A
B
C
D
C. Horn Button : ( ) Press button for
sounding horn.
D. Pass Switch : Press the switch to flash
the head light. It is used to give signal to
vehicles coming from opposite side while
overtaking.
Left Handle Bar Switches
A. High/Low Switch : When headlight is ON,
High or Low beam can be selected with
this switch. Hi beam indicator light located
on Speedo console will light up when high
beam is selected.
: High Beam : Low beam
B. Turn Signal Switch : When the turn signal
knob is pushed to Left ( ) or Right ( )
respective indicator will start blinking, to
exit push the knob in & release.
13

Pulsar AS 150 Specifications

General

Displacement	149.5 cc
Fuel System	Carburetor
Fuel Tank Capacity	15 L
Compression Ratio	9.5:1
Frame Type	Double Cradle
Max Torque	13.4 Nm @ 6000 rpm
Transmission	5 Speed
Front Suspension	Telescopic
Front Brake	Disc
Rear Brake	Drum
Clutch	Wet Multiplate
