Mode М (manual). Close the lens cover, turn the device on with a
short press of the ON button (11). Having finished calibration, open
the lens cover.
Mode SA (semi-automatic). Calibration is activated with a short
press of the ON button. You do not have to close the lens cover (the
sensor is closed with the internal shutter automatically).
Mode А (automatic). The device calibrates by itself according to the
software algorithm. You do not have to close the lens cover (the
sensor is closed with the internal shutter automatically). User
assisted calibration with the ON button is allowed in this mode (in
semi-automatic mode).
9
10
Enter the menu with a short press of the М (9) button.
To toggle between the functions below, press successively the M
button.
Brightness – press the UP (10)/ DOWN (8) buttons to change
display brightness from 00 to 20.
Contrast – press the UP/ DOWN buttons to change display
contrast from 00 to 20.
Digital zoom - press the UP/ DOWN buttons to change digital
zoom from 1.0x to 4.0x (or 8.0x in XP models). Continuous digital
zoom is in 0.1x increments.
The initial value of the continuous digital zoom is x1.0 if the step-up
digital zoom is not active.
STEP-UP DIGITAL ZOOM
10
The device allows you to quickly increase the basic magnification
(please refer to the line in the specifications table) by two “Digital zoom”
times or four times (8 times in XP models), as well as to return to the basic
magnification. To operate the step-up digital zoom, press successively
the button. DOWN (8)
QUICK MENU FUNCTIONS
11
The Quick menu allows change of basic settings (display brightness and
contrast, continuous digital zoom and stadiametric rangefinder).
Notes.
- actual magnification is the product of the basic magnification value and
continuous digital zoom value. For example: the device's basic
magnification is 3.0х, continuous digital zoom value х1.7. Actual
magnification is 5.1х (3.0*1.7).
- display brightness and contrast settings are saved in the memory when
the unit is turned off.
The stadiametric rangefinder — press the UP/ DOWN buttons to
change distance to an object being ranged (please refer to section 16 for
more details).
Enter the main menu with a long press of the М (9) button.
Press the UP (10)/ DOWN (8) buttons to switch between the menu
options.
Menu navigation is cyclical: as soon as the last menu option of the
first tab is reached, first menu option of the second tab starts.
Enter a menu option with a short press of the М button.
Exit the menu with a long press of the М button.
Automatic exit takes place in 10 sec of inactivity.
Upon exit from the menu the cursor location is memorized only for
the duration of the working session (i.e. until the unit is turned off).
Upon restarting the device and entering the menu the cursor will be
located on the first menu option.
MAIN MENU FUNCTIONS
12
TAB 1
MENU CONTENTS:
TAB 2
Menu Wi-Fi activation
Off
Off
Black Hot
Automatic
Menu General settings
+
10
