16
Connecting Garden Hose to Pressure Washer (See fig 7)
•
•
Inspect inlet screen and remove any debris.
•
Connect hose to water inlet and tighten by hand. There must be a minimum of 10 feet of unrestricted hose between
pressure washer and faucet or shut off valve.
•
Turn on water.
•
Purge the system’s pump of air by releasing the safety and squeezing the trigger of the spray gun.
FIG 7
Connect High Pressure Hose to Pump (See Fig 8)
•
Attach end of high pressure hose to the high pressure outlet on pump.
•
Follow the same procedure with opposite end to attach high pressure hose to spray wand.
FIG 8
Do not run pump without connecting to the water supply and turning water on. Failure to
do so could damage the pressure washer. Failure to follow these instructions will void
product warranty.
