E
G
F
Control Switches
Right Handle Bar Switches
E. Head Light Switch : It has 3 positions.
: All lamps 'OFF'.
: With engine running, Tail lamp,
Meter lamp, Pilot lamp/s, number
plate lamp will glow.
: With engine running, Head lamp,
Pilot lamp/s, Tail lamp ,Meter lamps
and number plate lamp will glow.
F. Starter Button :
Starter button operates the electric starter
when clutch lever is depressed with
transmission in any gear.
It is recommended to start the engine
with the transmission in neutral.
G. Engine Kill Switch :
The engine kill switch is for emergency
use. During emergency move the engine
kill switch to the ‘OFF’ ( ) position.
Speedometer display will work when both Ignition
switch & kill switch are in ‘ON’ position.
CAUTION : While starting ensure that
engine kill switch is in ON ( ) position.
Engine will not start if the kill switch
is in OFF position
13
